5000L 4-Layer Large High-Precision Water Tank Blow Molding Machine with Efficient
| Plaats van herkomst | CHINA |
|---|---|
| Merknaam | HUAYU |
| Certificering | ISO9001 CE |
| Modelnummer | HYBM5000-4 |
| Min. bestelaantal | 1 set |
| Prijs | 460000 USD |
| Verpakking Details | worden in vele delen gedemonteerd voor containervervoer |
| Levertijd | 4 maanden |
| Betalingscondities | T/t, l/c |
| Levering vermogen | 1 set 120 dagen |
Neem contact met me op voor gratis monsters en coupons.
WhatsApp:0086 18588475571
wechat: 0086 18588475571
Skype: sales10@aixton.com
Als u zich zorgen maakt, bieden we 24-uurs online hulp.
xProductdetails
| Koelwaterverbruik | 60m3/h | Klemkracht | 2500 kn |
|---|---|---|---|
| Automatisch | Ja | Voedingsmotor | 2.2kw*8 |
| Koelsysteem | Waterkoeling | Spanning | Klant |
| Productmateriaal | HDPE | Stroomvoorziening | 380V/50Hz |
| Jaar | 2024 | Lagen | 4 lagen |
| Parison | MOOG 200punten | After Sales | Overzeese service |
| Totaal gewicht | 50t | Beschikbare productie | watervat, ander kunststofproduct |
| Luchtvoorziening | 0.8*6 ((Mpa* kubieke meter per minuut) | ||
| Markeren | 5000L water tank blow molding machine,4-layer high-precision blow molding machine,large water tank molding machine with warranty |
||
U kunt de producten die u nodig heeft aanvinken en met ons communiceren op het mededelingenbord.
Productomschrijving
This high-precision blow molding machine with a 5000L capacity and 4-layer co-extrusion is designed for producing high-quality, multi-layered plastic products. The integrated water tank system ensures accurate temperature control and consistent cooling, resulting in superior product quality. The machine's advanced control system offers precise control over the molding process, ensuring consistent product dimensions and quality. Its durable construction and reliable performance make it suitable for industries requiring high-precision plastic products. The water tank is designed for easy maintenance and long-term reliability, making this machine a cost-effective and efficient solution for your production needs.
|
blowing and cooling system |
||
|
stretching stroke |
according to products |
|
|
blow pin up/down stroke |
600mm |
|
|
air seat stroke |
400mm |
|
|
maximum air pressure |
0.8Mpa |
|
|
air consumption |
3m3/min |
|
|
Cooling method |
Circulating water |
|
|
Water pressure |
0.3MPa |
|
|
ling water consumption |
75m3/h |
|
|
Hydraulic system |
||
|
main oil tank capacity |
1500L |
Servo motor, less energy consumption, high efficiency, low noise |
|
main oil pump |
gear pump185CC |
|
|
main oil pump motor |
60kw |
|
|
Servo oil tank capacity |
200L |
|
|
Servo oil pump model |
Plunger pump35 |
|
|
Servo oil pump motor |
11kw |
|
