5000L 1-Layer Large Customized Water Tank Blow Molding Machine with Customized
| Plaats van herkomst | CHINA |
|---|---|
| Merknaam | HUAYU |
| Certificering | ISO9001 CE |
| Modelnummer | HYBM5000-1 |
| Min. bestelaantal | 1 set |
| Prijs | 340000 USD |
| Verpakking Details | worden in vele delen gedemonteerd voor containervervoer |
| Levertijd | 4 maanden |
| Betalingscondities | L/c, t/t |
| Levering vermogen | 1 set 120 dagen |
Neem contact met me op voor gratis monsters en coupons.
WhatsApp:0086 18588475571
wechat: 0086 18588475571
Skype: sales10@aixton.com
Als u zich zorgen maakt, bieden we 24-uurs online hulp.
xProductdetails
| Vermindering | 250*2, 280*4 | Voordelen | 20 jaar ervaring |
|---|---|---|---|
| Gemiddelde kracht | 390 kW | Reinigingsmethode | Het gemakkelijke Schoonmaken |
| Machinedimensie | 8 maal 9 maal 6.5 | Machinegrootte | 7.2x3.3x5.5m |
| Schroefmateriaal | 38CrMoAlA,nitrideren | Garantie | 1 jaar |
| Versnellingsbak | Guigo | Vermogen van de extruderende motor | 7.5-15 kW |
| Accumulatorcapaciteit | 60 kg | Voordeel | Efficiënter en stabieler |
| Gemiddelde Consumptie | 350 kW | Maximale luchtdruk | 0,8 mpa |
| Voedingsmotor | 2.2kw*8 | ||
| Markeren | 5000L water tank blow molding machine,customized blow molding machine for water tanks,large 1-layer water tank molding machine |
||
U kunt de producten die u nodig heeft aanvinken en met ons communiceren op het mededelingenbord.
Productomschrijving
This customized blow molding machine with a 5000L capacity and 1-layer co-extrusion is designed to meet specific production requirements. The water tank system ensures efficient cooling and heat dissipation, maintaining optimal operating temperatures and enhancing production efficiency. The machine's customizable design allows for various product shapes and sizes, making it suitable for multiple industries. Its advanced control system offers precise control over the molding process, ensuring consistent product quality. The water tank is designed for easy maintenance and long-term reliability, making this machine a cost-effective and efficient solution for your production needs.
|
Clamping System |
||
|
platen size |
2100*2200*60mm(W*H*T) |
smooth running, no noise; the clamping force is big |
|
clamping cylinder |
160*2 320*1 |
|
|
clamping cylinder stroke |
2100mm |
|
|
clamping force |
2200KN |
|
|
distance between platens |
1100-3200mm |
|
|
max. mould size |
1800*2200mm(W*H) |
|
|
blowing and cooling system |
||
|
stretching stroke |
according to products |
|
|
blow pin up/down stroke |
600mm |
|
|
air seat stroke |
400mm |
|
|
maximum air pressure |
0.8Mpa |
|
|
air consumption |
3m3/min |
|
|
Cooling method |
Circulating water |
|
|
ater pressure |
0.3MPa |
|
|
ooling water consumption |
75m3/h |
|
